Operating Conditions
- Relative humidity: Not more than 90%.
- The surrounding working environment shall be free of flammable, explosive, and corrosive gases.
- The altitude of the use location complies with GB755-2008.
- For outdoor environments subject to rain and snow erosion or exposed to corrosive gases and media, anti-corrosion products shall be used.
Performance
| Brake Type | Compatible Thruster | Braking Torque | Brake Clearance | Weight(kg) |
| YWZ4B-100/E23 | Ed23/5 | 40 | 0.6 | 21 |
| YWZ4B-150/E23 | Ed23/5 | 100 | 0.6 | 25 |
| YWZ4B-150/E30 | Ed30/5 | 120 | 29 | |
| YWZ4B-200/E23 | Ed23/5 | 200 | 0.7 | 31 |
| YWZ4B-200/E30 | Ed30/5 | 230 | 34 | |
| YWZ4B-300/E30 | Ed30/5 | 320 | 0.7 | 65 |
| YWZ4B-300/E50 | Ed50/6 | 630 | 78 | |
| YWZ4B-300/E80 | Ed80/6 | 750 | 79 | |
| YWZ4B-400/E50 | Ed50/6 | 1000 | 0.8 | 128 |
| YWZ4B-400/E80 | Ed80/6 | 1600 | 140 | |
| YWZ4B-400/E121 | Ed121/6 | 2000 | 155 | |
| YWZ4B-500/E121 | Ed121/6 | 2500 | 0.8 | 210 |
| YWZ4B-500/E201 | Ed201/6 | 3600 | ||
| YWZ4B-600/E121 | Ed121/6 | 3200 | 0.8 | 390 |
| YWZ4B-600/E201 | Ed201/6 | 5000 | 390 | |
| YWZ4B-700/E201 | Ed201/6 | 8000 | 0.8 | 465 |
| YWZ4B-700/E301 | Ed301/12 | 8650 | 466 | |
| YWZ4B-800/E301 | Ed301/12 | 12500 | 0.9 | 785 |
Advantages
All main swinging hinge points are equipped with self-lubricating bearings, featuring high transmission efficiency and requiring no lubrication during use.
The brake linings can be installed in two forms as per user requirements: riveted type and inserted type (please specify when placing an order).
