Performance
| Brake Model | Braking Torque(N.m) | Retreat rectangle | Weight(Kg) | |
| (mm) | ||||
| Brake Model | Match Booster | |||
| YWZ8-200/E23 | Ed23/5 | 135-200 | 0.7 | 35 |
| YWZ8-200/E30 | Ed30/5 | 135-310 | 43 | |
| YWZ8-300/E30 | Ed30/5 | 200-320 | 1 | 65 |
| YWZ8-300/E50 | Ed50/6 | 200-550 | 80 | |
| YWZ8-300/E80 | Ed80/6 | 350-850 | 92 | |
| YWZ8-400/E50 | Ed50/6 | 600-750 | 1 | 120 |
| YWZ8-400/E80 | Ed80/6 | 600-1300 | 130 | |
| YWZ8-400/E121 | Ed121/6 | 850-2000 | 150 | |
| YWZ8-500/E121 | Ed121/6 | 1000-2600 | 1.2 | 220 |
| YWZ8-500/E201 | Ed201/6 | 1500-3700 | ||
| YWZ8-600/E121 | Ed121/6 | 1700-2800 | 1.3 | 360 |
| YWZ8-600/E201 | Ed201/6 | 1700-4300 | ||
| YWZ8-600/E301 | Ed301/6 | 3000-6500 | ||
| YWZ8-700/E201 | Ed201/6 | 3000-5000 | 1.3 | 450 |
| YWZ8-700/E301 | Ed301/6 | 3700-8000 | ||
| YWZ8-800/E301/12 | Ed301/12 | 6000-10000 | 1.6 | 560 |
Advantages
Safe and reliable performance, smooth braking, and high action frequency.
The interlocking equal back-off device ensures that the back-off on both sides of the brake pads remains equal during use, preventing the phenomenon where one side of the brake pad floats and sticks to the brake wheel due to uneven back-off.
The main swinging hinge points are equipped with self-lubricating bearings, providing high transmission efficiency and long service life, without the need for lubrication during use.
Asbestos-free brake pads and brake blocks are designed with a snap-in insertion method.
They are safe, reliable, and easy to replace quickly.
